Compare Model Drawings, CAD & Specs Availability Price
Bar Code Scanner Power Sensor, Silicon, 0.1-20 mW, 10x10 mm, 400-1100 nm
In Stock
In Stock


  • Aperture Size
    10 x 10 mm
  • Material
  • Spectral Range
    400-1100 nm
  • Power Range
    0.1 mW to 20 mW
  • Maximum Average Power Density
    50 W/cm²
  • Dimensions
    118 x 10 x 18 mm (LxWxD)
  • Use
    1.5 m
  • CE Compliance
  • UKCA Compliance
  • China RoHS Compliance


Measuring Power of Scanned Beams Using BC20

In this video, you will learn how the BC20 sensor enables correct power measurement of scanned beams, such as are used in barcode readers, laser shows and similarly challenging applications.

Measuring Very Low Laser Powers with a Photodiode Sensor

In this short “Basics” video, we review in general the use of photodiode sensors for measuring very low laser powers.
