Weapon Sights and Handheld Imagers

轻巧、紧凑、热成像透镜，适用于手持式国防应用

产品特征

超轻型变焦和定焦镜头
高光学性能
低功耗
高耐久性或硬碳低反射（LRHC）增透膜
快速视场切换
在连续变焦的整个变焦过程中F#保持不变
精准的光轴一致性
兼容多种主要的中波红外和长波红外探测器
衍射极限的光学设计
无热化补偿
整个变倍范围内保持齐焦性
预设的离散光学变焦位置
通过RS 485或RS 232控制CPU

LWIR Lenses for TWS and HHTI

	型号	功能
	SupIR 25 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +70°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 25 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens
	SupIR 40 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 40 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens
	SupIR 50 mm f/1.2 Fixed 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 50 mm f/1.2 Fixed 1-FOV LWIR XGA Imaging Lens
	SupIR 55 mm f/1.0 Fixed 1-FOV LWIR Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 10 & 12 μm pixel pitch, 640x480 VGA format LWIR cameras		SupIR 55 mm f/1.0 Fixed 1-FOV LWIR Imaging Lens
	SupIR 60 mm f/1.25 Fixed 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 60 mm f/1.25 Fixed 1-FOV LWIR XGA Imaging Lens
	SupIR 65 mm f/1.25 Manual 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR Hard-carbon AR coating for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 65 mm f/1.25 Manual 1-FOV LWIR XGA Imaging Lens
	SupIR 73.1 mm f/1.05 Fixed 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 10 & 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 73.1 mm f/1.05 Fixed 1-FOV LWIR XGA Imaging Lens
	SupIR 75 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR High-durability and hard-carbon AR coatings for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +60°C Compatible with 10 & 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 75 mm f/1.0 Manual 1-FOV LWIR XGA Imaging Lens
	SupIR 75 mm f/1.2 Manual 1-FOV LWIR XGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR Hard-carbon AR coating for 8-12 µm Passive athermalization with the highest imaging performance from -30 to +70°C Compatible with 12 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 75 mm f/1.2 Manual 1-FOV LWIR XGA Imaging Lens
	SupIR 100 mm f/1.6 Manual 1-FOV LWIR SXGA Imaging Lens	Advanced technologies for the highest performance long wave focal planes LWIR Hard-carbon AR coating for 8-12 µm Passive athermalization with the highest imaging performance from -40 to +80°C Compatible with 12 & 17 μm pixel pitch, 1024x768 XGA format LWIR cameras		SupIR 100 mm f/1.6 Manual 1-FOV LWIR SXGA Imaging Lens

MWIR Lenses for TWS and HHTI

	型号	功能
	LightIR 10-135 mm f/3.6 Motorized MWIR Zoom Imaging Lens	Meets low SWaP demand with long EFL Efficient folded optics design for max. volume use Designed for MWIR 10 μm pitch 640x512 sensors Ideal for mini/ micro tactical payloads		LightIR 10-135 mm f/3.6 Motorized MWIR Zoom Imaging Lens
	LightIR 18-225 mm f/4.0 Motorized MWIR Zoom SXGA Imaging Lens	Efficient compact optics design for max. volume use Designed for MWIR 10 µm SXGA and 15 µm VGA Detectors Ideal for mini/micro tactical payloads Detection range exceeds 16 km		LightIR 18-225 mm f/4.0 Motorized MWIR Zoom SXGA Imaging Lens
	LightIR 20–275mm f/5.5 MWIR Motorized Continuous Zoom Lenses	Smallest, most lightweight continuous zoom lens on the market Long-range capabilities of up to 14.9 km detection range Unique optomechanical design and focus movement High-durability and low reflection hard-carbon 3-5 µm wavelength AR coatings		LightIR 20–275mm f/5.5 MWIR Motorized Continuous Zoom Lenses

Resources

Thermal Weapon Sights And Hand-Held Ir Optical Solutions(4.2 MB, PDF)
